LC-H 80W UL TUV CB CE Dimmable Constant Current LED Driver for Street Lighting

  • Constant current mode
  • Non-isolated power supply with plastic case
  • Build-in 3-in-1, intelligent time isolated dimming function, dim off or not
  • Isolated auxiliary power +12V ( Optional )
  • Light control function ( Optional )
  • Build in protection function of short circuit, over current, over voltage and over temperature

Item: LC-80NH
Power: 80W
Application: Flood light, stage ligh, area light and high-pole light
Certificates: UL ClassP, TUV, CB, CE
5 Years Warranty

Features of 80W UL TUV CB CE Dimmable Constant Current LED Driver

Efficiency up to 92%
Isolated Dimming (Optional): 1-10V, PWM, Resistor
Light Control Function(Optional)
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 4kV, L/N-PE: 6kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LC-80N062HA (100-277) Vac (37-62) Vdc 0.9-1.3 A 80W
