LG-20M LED Power Driver ( LED Power Supply )

LG 20W UL TUV CCC CE Dimmable Constant Current LED Power Supply with Surge Protection

  • Constant current mode
  • Isolated power supply with plastic case
  • Build in protection function of short circuit, over current, over voltage and over temperature
  • With 1-10v dimming function
Category:

Item: LG-20M
Power: 20W
Application: Flood light, Stage light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of 20W  Dimmable Constant Current LED Power Supply

Efficiency up to 86%
Dimming(Optional): 0-10V, PWM, Resistor
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 2kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LG-20M023 (100-277)Vac (11-23)Vdc (0.6-1)A 20W
LG-20M042 (100-277)Vac (24-42)Vdc (0.35-0.6)A 20W
LG-20M054 (100-277)Vac (33-54)Vdc (0.25-0.4)A 20W
