LG-25M LED Power Driver ( LED Power Supply )

LG 25W Surge Protection UL TUV CCC CE Dimmable Constant Current LED Power Supply

  • Constant current mode
  • Isolated power supply with plastic case
  • Build in protection function of short circuit, over current, over voltage and over temperature
  • With 1-10v dimming function
Category:

Item: LG-25M
Power: 25W
Application: Flood light, Stage light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of 25W Surge Protection  Dimmable Constant Current LED Power Supply

Efficiency up to 86%
Dimming (Optional): 0-10V, PWM, Resistor
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 2kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LG-25M023 (100-277)Vac (11-23)Vdc (0.9-1.3)A 25W
LG-25M033 (100-277)Vac (20-33)Vdc (0.6-0.9)A 25W
LG-25M054 (100-277)Vac (33-54)Vdc (0.37-0.55)A 25W
