LI 30W IP65 Dimmable Constant Current LED Power Supply ( UL TUV CCC CE LED Power Driver )

Constant current mode
Isolated power supply with iron case
Isolated with double stage circuit, flicker free
Build-in 3-in-1, intelligent time isolated dimming function, dim off or not
Isolated auxiliary power ( +12V, +24V )
Build in protection function of short circuit, over current, over voltage and over temperature

Item: LI-30M
Power: 30W
Application: LED indoor lighting drivers. also available for street light, highbay, flood light, stage light and high-pole light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of 30W IP65 Dimmable Constant Current LED Power Supply

Efficiency up to 86%
Isolated Dimming (Optional): 0-10V,PWM,Resistor and Timming
IP65
Protections: SCP/OTP/OVP/OPP
Surge Protection: L-N: 2kV, L/N-PE: 4kV
Operation temperature: -30~+55

Model	AC Input Range	DC Output Range	Output Current	Output Power
LI-30M042	(100-277)Vac	(25-42)Vdc	0.5-0.85A	30W
LI-30M055	(100-277)Vac	(42-55)Vdc	0.3-0.65A	30W
LI-30M090	(100-277)Vac	(55-90)Vdc	0.2-0.4A	30W
