LC-80MHA LED Power Driver ( LED Constant Current Supply )

LC-HA 80W 5 Years Warranty LED Constant Current Power Supply with High Surge Protection

  • Constant current mode
  • Non-isolated power supply with plastic case
  • Build-in 3-in-1, intelligent time isolated dimming function, dim off or not
  • Isolated auxiliary power +12V ( Optional )
  • Light control function ( Optional )
  • Build in protection function of short circuit, over current, over voltage and over temperature
Category:

Item: LC-80MHA
Power: 80W
Application: Flood light, Stage light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of 80W 5 Years Warranty LED Constant Current Power Supply

Efficiency up to 91%
Isolated Dimming(Optional): 1-10V, PWM, Resistor
Light Control Function(Optional)
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 4kV, L/N-PE: 6kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LC-80M062HA (100-277)Vac (37-62)Vdc (0.9-1.3)A 80W
