LB 100W 1-10V Isolated Dimming Constant Current LED Power Supply with SCP OCP OVP OTP

  • Constant current mode
  • Non-isolated double stage power supply with aluminium case
  • Output current adjustable
  • Build-in 3-in-1, intelligent time isolated dimming function, dim off or not
  • Isolated auxiliary power ( +5V, +12V, +24V )

Item: LB-100N
Power: 100W
Application: Street light, Highbay, Flood light, Stage light and High-pole light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of

Efficiency up to 92%
Isolated Dimming (Optional): 1-10V, PWM, Resistor and Timming
IP67
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 4kV, L/N-PE: 4kV



Model AC Input Range DC Output Range Output Current Output Power
LB-100N130 (100-277)Vac (70-130)Vdc 0.7-1.0A 100W
LB-100N180 (100-277)Vac (120-180)Vdc 0.45-0.6A 100W
LB-100N260 (100-277)Vac (200-260)Vdc 0.35-0.45A 100W
